LCP Hook Locking Plates
A titanium plate in the Oltho Upper Extremity catalog, in the Shoulder section, with 3 reference numbers.

PlateTitanium
Titanium plate for Ø3.5 mm locking and cortex, Ø4.0 mm cancellous screws, 3, 4 and 5 holes, lengths 52.3 to 76.5 mm; 3 references.
- Screws
- Ø3.5 mm locking and cortexØ4.0 mm cancellous
- Holes
- 3, 4, 5
- Length
- 52.3, 64.2, 76.5 mm
- Plate Thickness
- 3.00 mm
- Plate Shaft Width
- 10.30 mm
- Shaft Hole Spacing
- Variable
- In the catalog
- Upper Extremity, Shoulder
Reference numbers
3 references
| Ref. no. | Holes | Length |
|---|---|---|
| 3 | 52.3 mm | |
| 4 | 64.2 mm | |
| 5 | 76.5 mm |
